The single shaft shredder mainly consists of blade shaft, fixed knife, carrying box, box support, feeding system, hydraulic pushing system, power system, electrical control system etc. The single shaft shredder can meet various industries that recycle all kinds of waste material. It applies to plastic, paper, wood, fiber, rubber, domestic waste etc.
Model 型号 | LTSS-600 | LTSS-800 | LTSS-1000 | LTSS-1200 | LTSS–1500 |
The length of rotor 转子长度(mm) | 600 | 800 | 1000 | 1200 | 1500 |
The diameter of rotor 转子直径(mm) | Ф280 | Ф400 | Ф400 | Ф400 | Ф550 |
Main motor power 主电机功率(kW) | 37 | 45 | 55 | 75 | 90 |
Hydraulic power 液压功率(kW) | 1.5 | 2.2 | 3 | 3 | 4 |
Qty. of rotary knives 动刀数量(Pcs) | 26 | 34 | 56 | 80 | 112 |
Qty. of fixed knives 定刀数量(Pcs) | 2 | ||||
The wall thickness of box 箱体壁厚(mm) | 20 | 25 | 30 | 35 | 35 |
Output capacity 产能(kg/h) | 300 | 500 | 700 | 900 | 1200 |
