LTMF Series Plastic Pulverizer

MFS Series Plastic Pulverizer With Cutter

Based on the advanced technology from abroad, we design and manufacture the MFS series pulverizer with the cutter to meet customers from China and abroad. It is an ideal machine to process and grind hard and crisp plastic material such as PVC. And it also is a special machine to recycle leftover material.

Model 型号	MFS-400	MFS-500	MFS-600	MFS-800	MFS-1000
The inner diameter of pulverizing chamber 磨粉室内径(mm)	400	520	620	820	1000
Qty. of rotary knives 动刀数量(Pcs)	20	22	26	32	40
Qty. of fixed knives 定刀数量(Pcs)	11	12	14	19	24
Main shaft speed 主轴转速(rpm)	3800
Main motor power 主电机功率(kW)	45		55	75	110
Power of suction fan 吸料风机功率(kW)	5.5	5.5	7.5	11	15
Power of off fan 关风机功率(kW)	0.75			1.1
Vibration motor power 振动电机功率(kW)	0.55			0.75	1.1
Output capacity 产能(kg/h)	200	250	300-350	600-700	800-900

MG Series Plastic Pulverizer With Grinding Disc

MG series pulverizer with the grinding disc is mainly used for soft and resilient material such as PP, PE. And it is a special machine to recycle leftover material. MG series pulverizer with grinding disc and MFS series pulverizer with cutter have same working principle. The only difference is the structure of the knives.

Model 型号	MG-400	MG-500	MG-600	MG-800	MG-1000
The inner diameter of pulverizing chamber 磨粉室内径(mm)	400	520	620	820	1000
Qty. of rotary knives 动刀数量(Pc)	1
Qty. of fixed knives 定刀数量(Pc)	1
Main shaft speed 主轴转速(rpm)	3800
Main motor power 主电机功率(kW)	55		75	90	132
Power of suction fan 吸料风机功率(kW)	5.5		7.5	11	15
Power of off fan 关风机功率(kW)	0.75			1.1
Vibration motor power 振动电机功率(kW)	0.55		0.75		1.1
Output capacity 产能(kg/h)	70-80	80-100	150-200	350-400	500-600
