LTPC Series Crusher(Granulator)

 LTPC series crusher is mainly used for small and thin wall products such as injection basins, bottles, and small electronic products. It especially applies to sub-quality products recycled by products factory. Working principle: The motor of the crusher drives rotary knives to do high-speed rotational motion and form relative motion with fixed knives. Taking advantage of the gap between rotary knives and fixed knives, plastic material will be crushed. The plastic material after being crushed will through the screen mesh to filter and output.

Model 型号

LTPC-250

LTPC-300

LTPC-400

LTPC-500

LTPC-600

Main motor power

主电机功率(kW)

4

5.5

7.5

15

18.5

The diameter of rotor

转子直径(mm)

Ф200

Ф250

Ф300

Ф380

Ф450

Rotor speed

转子转速(rpm)

750

Output capacity

产能(kg/h)

80-120

200-280

250-350

300-400

400-500

Qty. of rotary knives

动刀(Pcs)

6

Qty. of fixed knives

定刀(Pcs)

2

4

The thickness of blade

刀片厚度(mm)

18

20

The wall thickness of box

破碎机箱体壁厚(mm)

14

16

20

The wall thickness of knife frame

刀架壁厚(mm)

20

30

Bearing

轴承

ZWZ or others

瓦轴
