LTSWP Series Crusher(Granulator)

LTSWP series crusher is mainly used to crush all kinds of profiles, pipes including plastic door, plastic plate, window frame, trunking, sheet and plastic pipes etc. For the long and small diameter PE, PVC, PPR pipes, we can feed them continuously and do not need to cut them. And for the big diameter and thick pipes, we need to cut them into small section and then crush.

Model 型号	SWP-200	SWP-320	SWP-400	SWP-500	SWP-600	SWP-700	SWP-800	SWP-1000
Main motor power 主电机功率(kW)	5.5	7.5	11	22	30	30	45	55
The diameter of rotor 转子直径(mm)	Ф200	Ф250	Ф300	Ф350	Ф350	Ф400	Ф450	Ф 650
Rotor speed 转子转速(rpm)	750
Output capacity 产能(kg/h)	100	200	300	400	500	600	700	900
Qty. of rotary knives 动刀(Pcs)	6
Qty. of fixed knives 定刀(Pcs)	2				4
The thickness of blade 刀片厚度(mm)	20						25
Material of screen mesh 筛网材质	Manganese steel or others 锰钢板
The wall thickness of box 破碎机箱体壁厚(mm)	14		16	18	20	25	30	35
The wall thickness of knife frame 刀架壁厚(mm)	30			45		50		55
Bearing 轴承	ZWZ or others 瓦轴
Volume of silo 料仓容积(L)	100		200		300		400	600
Material of silo 料仓材质	SUS304
Power of suction fan 吸料风机功率(kW)	3		4		5.5			7.5
